- ≥ 500 kg Load Capacity in Compact Form Despite a vehicle weight of ≤ 500 kg, the platform carries payloads of at least 500 kg, providing a high payload-to-mass ratio suited to underground equipment and material transport.
- Remote Operation from Safe Distance Designed for remote control from a safe standoff, keeping operators away from unstable ground, confined headings, and other underground hazards during transport and logistics tasks.
- Modular, Low-Maintenance Design The modular architecture allows straightforward component replacement and easy servicing, reducing maintenance downtime and supporting extended operational availability in mining environments.
- 4-Hour Shift-Aligned Endurance A 4-hour operational endurance supports structured mining shift cycles, enabling repeated shuttle runs and logistics tasks within a single shift before recharging.
- Compact Tracked Chassis for Confined Spaces The tracked drivetrain and compact 2,200 × 1,400 mm footprint enable stable movement through narrow mine roadways and constrained underground layouts where larger vehicles cannot operate.
Descrizione
The Topsky LTXZC-1206-3 is a compact tracked unmanned ground vehicle (UGV) engineered for logistics, material transport, and remote operations in underground mine environments. Built on a chassis measuring 2,200 mm × 1,400 mm × 1,200 mm, the platform achieves a rated load capacity of at least 500 kg despite a total vehicle weight of no more than 500 kg—a high payload-to-mass ratio that makes it effective for moving tools, parts, cables, and mission payloads through constrained mine roadways. A maximum travel speed of 1.5 m/s supports controlled, stability-first movement appropriate for underground sites, while a 4-hour endurance rating suits shift-structured operations with planned recharge intervals between task cycles.
Designed specifically for narrow and complex underground layouts, the LTXZC-1206-3 can be operated remotely from a safe standoff distance, reducing the need to put personnel in areas with unstable ground, limited air quality, or restricted access routes. A modular design with emphasis on low maintenance cost and easy serviceability allows operators to replace wear components and adapt the platform for different mission requirements without extensive downtime. Topsky positions the LTXZC-1206-3 as a straightforward-to-operate solution for mine sites seeking to improve equipment transport logistics and personnel safety simultaneously.
Caratteristiche
Specifiche
| Brand | Topsky |
|---|---|
| Model | LTXZC-1206-3 |
| Dimensions (L×W×H) | 2200 mm × 1400 mm × 1200 mm |
| Weight | ≤ 500 kg |
| Load Capacity | ≥ 500 kg |
| Maximum Speed | 1.5 m/s |
| Endurance | 4 hours |
| Operation Mode | Remote control from safe distance |
| Design Architecture | Modular (low maintenance cost) |
| Origin | China |
Settori industriali
Domande frequenti
The Topsky LTXZC-1206-3 is a compact tracked unmanned ground vehicle (UGV) designed for material transport and logistics operations in underground mine environments. It carries loads of at least 500 kg, operates under remote control from a safe standoff distance, and is built with a modular design for easy maintenance in demanding underground conditions.
The platform's compact tracked chassis allows movement through narrow mine roadways and constrained underground layouts. Remote operation from a safe distance keeps personnel away from hazardous areas, while the ≥ 500 kg load capacity handles real transport loads including tools, cables, parts, and mission fixtures. A 4-hour endurance aligns with standard mining shift structures.
The LTXZC-1206-3 targets underground mining for material transport, equipment logistics, and remote-operation tasks in areas with limited or hazardous access. Its compact, heavy-payload capability also makes it relevant in industrial tunnel environments and confined-space logistics where conventional transport is impractical.
Yes, Robotix Market ships worldwide to qualified mining and industrial customers. The LTXZC-1206-3 is covered by the manufacturer's warranty as provided by Topsky; no on-site installation or maintenance service is included with the standard purchase. Contact us for regional shipping logistics and lead time details.
Submit a quote request through the Robotix Market website or contact our team directly. We confirm pricing, configuration options, and shipping arrangements on a per-order basis and can support procurement teams with technical documentation.
